Sunday Blueprint

The Blueprint is a bike for new riders that is built around a pro-level geometry to help them progress faster.

This bike is equipped with hassle-free parts like Odyssey Springfield brakes, a Sunday Freeze stem and Current v1 2.4” tires to help keep you focused on the important part - riding. The Blueprint comes with an integrated head tube this year for greater durability, ease of assembly and pro style points.

Key Features

• Sunday Current v1 Tires

• Odyssey Springfield Brakes

• FSA Integrated Headset

• Sunday Cornerstone Grips

• Sunday Freeze Front Load Stem

• Sunday Sabretooth v2 Sprocket

• KMC S1 Chain

Specifications

Frame: Sunday Blueprint, 20.5" top tube, integrated 1-1/8" head tube Fork: Sunday Blueprint, 20" fork w/ 2-piece steerer tube and welded pre-load Handlebar: Sunday, 2-piece Stem: Sunday Freeze front load, 48mm Headset: FSA integrated, 1-1/8" Alloy Cap: FSA aluminum cap Brake Lever: Aluminum, U-brake compatible Brakes: Odyssey Springfield U-brake Brake Cable: Odyssey Quik Slic Grips: Sunday Cornerstone Seat: Sunday Badge, seat and post combo Seat Post: Integrated Seat Clamp: Integrated Sprocket: Sunday Sabretooth v2, 25T, steel Cranks: 160mm, 3-piece, chromoly BB Parts: Loose-ball, American, 19mm Pedals: Wellgo platform, plastic Rims: P-7X aluminum, 20", 36H Front Hub: Sunday, 36H, low-flange, loose-ball, 3/8" axle Rear Hub: Sunday, 36H,14mm axle w/ 9t Driver Spokes: 14g steel, black Tires: Sunday Current v1, 20 x 2.4" (F & R) Chain: KMC S1 Approx. Weight: 26lbs (with brakes)

Frame Geometry

Top Tube Length: 20.5" Head Tube Angle: 75° Seat Tube Angle: 71° Chainstay Length: 13.2-13.5” Bottom Bracket Height: 11.5" Standover: 8.75"

Handlebar Geometry

Rise: 9" Width: 28.5" Backsweep: 12° Upsweep: 4°

--- *Specs subject to change without notice.
